Supercross BMX | The ENVY RS7 Fastback | Disc Brake Specific BMX Race Frame
$ 699.95 - $ 749.95$ 0.00
- Overview
- Materials
- Geometry
It's Evolutionary, not Revolutionary
SEE THE FULL PRODUCT DESCRIPTION & VIDEOS HERE
-
7005 URL Ultra Light triple-butted custom-shaped tubing
-
Enhanced BB support and power transfer
-
Cold-forged bottom bracket shells with cold-rolled threads
-
Fine-tuned butting profiles for perfect balance of strength, stiffness and weight
-
Revamped head tube shaping featuring thicker bearing race seats and walls
-
3D CNC’d rear dropouts
-
Fully boxed-in chainstays with 7005 sheet aluminum
-
Available in 18 different sizes and 12 different stock colors
The ENVY RS7 is built with the best materials, keeping you looking your best on the track.
The Supercross ENVY RS7 utilizes our special blend of 7005 ULR Ultra Light triple-butted custom-shaped tubing that is a direct result of working with Easton® Tubesets for over a decade. Why 7005 Aluminum, you ask? 7005 has higher strength and yield than 6061 when properly aged and heat treated. Kind of a Superhero of Aluminum. Sound too good to be true? We thought so too, but after a decade of real-world testing, we can tell you that this frame is the real deal. Ultra stiff, yet incredibly light.
Now to you Supercross fans, you will know that the 7005 ULR tubing has been used on all our ENVY Aluminum race frames for the last 10 years, so what makes the RS7 new?
The RS7 is the next evolution of the original ENVY frame. So it shares many of the previous improvements while bringing a few of its own to the party.
SUPERCROSS BMX ENVY RS7 ALUMINUM RACE FRAME GEOMETRY CHART
| Size | A | B | C | D | E | Post Size | Fork |
Wheel Size | Weight |
| Micro | 16.75" | 12.0" | 72º | 70º | 10.3" | 22.2mm | 1 Threadless | 20 X 1 | 2lbs |
| Mini | 17.5" | 12.25" | 72º | 70º | 10.7" | 22.2mm | 1 Threadless | 20 X 1 1/8 | 2lbs 1oz |
| Jr. | 18.5" | 12.5" | 73.5º | 70º | 10.7" | 22.2mm | 1 Threadless | 20 X 1 1/8 | 2lbs 2oz |
| Jr. Plus | 19" | 12.5" | 73.5º | 70º | 10.7" | 22.2mm | 1 Threadless | 20 X 1 1/8 | 2lbs 3oz |
| Expert | 19.5" | 13.75" | 74º | 70º | 11.2" | 22.2mm | 1 Threadless | 20 X 1 3/8 | 2lbs 5oz |
| Expert XL | 20" | 14.0" | 74º | 70º | 11.2" | 22.2mm | 1 Threadless | 20 X 1 3/8 | 2lbs 6.5oz |
| Expert XXL | 21" | 14.0" | 74.5º | 70º | 11.2" | 22.2mm | 1 Threadless | 20 X 1 3/8 | 2lbs 8.8oz |
| Pro | 20.5" | 15.0" | 74.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 20 X 1.75 | 2lbs 12oz |
| Pro Plus | 20.75" | 15.0" | 74.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 20 X 1.75 | 2lbs 13oz |
| Pro XL | 21.25" | 15.2" | 74.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 20 X 1.75 | 2lbs 14.8oz |
| Pro XXL | 21.75" | 15.2" | 74.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 20 X 1.75 | 2lbs 15.8oz |
| Pro XXXL | 22.25" | 15.2" | 74.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 20 X 1.75 | 3lbs 4oz |
| Pro XXXXL | 22.75" | 16" | 74.5º | 70º | 11.625" | 27.2mm | 1 1/8" - 1.5" Tapered | 20 X 1.75 | TBA |
| Junior 24" | 19.25" | 14.2" | 73.5º | 69.3º | 11.2" | 22.2mm | 1 Threadless | 24 X 1 1/8 | 2lbs 2oz |
| Expert 24" | 20.5" | 15" | 73.5º | 69.3º | 11.2" | 22.2mm | 1 Threadless | 24 X 1 3/8 | 2lbs 8.8oz |
| Expert XL 24" | 21" | 14.75" | 73.5º | 70º | 11.6" | 22.2mm | 1 Threadless | 24 X 1 3/8 | 2lbs 10oz |
| Pro 24" | 21.5" | 15.3" | 73.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 24 X 1.75 | 2lbs 15.8oz |
| Pro XL 24" | 22" | 15.3" | 73.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 24 X 1.75 | 3lbs 1.2oz |
| Pro XXL 24" | 22.5" | 15.3" | 73.5º | 70º | 11.6" | 27.2mm | 1 1/8" - 1.5" Tapered | 24 X 1.75 | |
| * Specifications will vary depending upon your choice of Fork, Tire and Rim selection. Measurements are based off of a Supercross Fork and equal size (ie. 20X1.75 front and rear) tire combination. Specifications subject to change without notice. | |||||||||
All weights are measured on a UPS Calibrated Scale. Weights will vary depending upon the amount of powdercoat and the amount of filler rod used on a particular frame. Polished Frames and Anodized Frames are the lightest as there is no paint. Weights and Specifications are subject to change without notice.
Please note: Pro Sized and Larger Frames have the LUG behind the BB shell for the increased Stiffness. Smaller Frames, Expert XXL and down, have a tube brace, but the Chain Stays are welded directly to the BB shell without the boxing.
-
Each Pro RS7 Frame Comes with the Frame, a set of 10mm Axle adapters and the 3 Brake Clips. Expert XXL and Smaller do not come with the adapters as they are not needed on the smaller frames.
-
Pro Size and Larger take the 1 1/8" Tapered Headset - We have our Speedline Version which you can purchase here.
And the Expert XL and Smaller Frames take a Campy® Integrated, and we have them in the 1 1/8" size which we recommend for the Expert and Larger Frames and the 1" Version for the Junior Plus and Smaller Frames. -
Pro size and Larger take a 31.9mm Clamp and a 27.2 Post. The Expert and smaller take a 22.2 post and a 25.4mm clamp. We have all of the posts and clamps in stock for you to finish the build.
-
This is a Chassis Kit, you will still need,
- Stem
- Spacers
- Bars
- Grips
- Brakes
- Wheels
- Tires & Tubes
- Cranks & BB Kit
- Chain
- Pedals
- Seat
- Seatpost and Seatpost Clamp
We stock most of these parts to be able to help you build it up , or you can swap parts over from your existing bike.
-
The RS7 is a V-Brake Specific Frame. People have ran the Disc Brake adapters on them sussesfully, but you have to be very careful on any BMX Frame with the horseshoe dropouts.
There is a Fastback version of the RS7, that has a thicker stay set to use the disc brake adapters. But it is still recomended to watch the Disc Adapters tightness at all times. -
The ENVY RS7 uses our World Championship winning Supercross BMX Race Geometry that has been refined over 3 decades of BMX racing. Feel free to look above this FAQ and click the geometry tab for a lowdown!
-
Unfortunately we do not sell team jerseys, but you can rep the Vision with any of our Lifestyle apparel, including a RS7 Shirt!
